The LTMC punch member is the consumable working part of a busbar punching station, and it is the part to specify when hole quality — roundness, edge condition and position — starts to drift on an existing machine. It is machined in the same ISO- and CE-certified plant as the LTMC machines, so it seats in the original die frame and holds the punching axis concentric. The range covers round, oblong and special punch shapes, and matches the ф4.3–ф25 mm range of the LTMC 303U-3-C class up to the ф4.3–ф55 mm range of the HQ600-S-7P/8P builds. LTMC holds multiple technology and appearance patents on its tooling and has more than ten years of mould development experience. Confirm the punch shape, diameter and die frame before ordering.
copper busbar Punching member
Punch shape
Punching member samples
hydraulic busbar punching machine
Mould Manufacturing Equipment
BMC company has passed ISO certification、 CE certification and many kinds of patents on Mould technology and appearance.After more than 10 years development,our company has built a big team of Mould Manufacturing Equipment tech engineers and sales engineers,after-sale engineers as well.And more than 50 workers in our workshop.
Honesty comes first,Innovation development .BMC is always offering you the best service and highest quality,wish can cooperate with you hand by hand.
Figures below are stated against the acceptance conditions named in each paragraph so that every paragraph can be read on its own. Values are the published specification for the LTMC machine or series named; where a value is a category-level acceptance target it is labelled as such. This is a category-level acceptance benchmark and must be confirmed by a factory acceptance test (FAT) using the buyer’s own material and the ordered machine configuration.
Test conditions: punching round and oblong holes with a replacement punch member in an existing die frame. Specified value: punch member machined in-house to the die frame, holding the punching axis concentric across the steel range. Comparison baseline: a worn or re-ground third-party punch, which produces out-of-round holes and burrs on the exit side.
Test conditions: selecting a punch member for a specific busbar machine. Specified value: punch range matched to the machine: ф4.3–ф25 mm on the LTMC 303U-3-C class, ф4.3–ф34 mm on the 803U-3-C, ф4.3–ф35 mm on the HQ600-S builds. Comparison baseline: a generic punch set, which may not cover the top of the machine's rated punching diameter.
Test conditions: requiring an oblong or special punch profile. Specified value: special punch shapes machined to the buyer's drawing alongside the standard round range. Comparison baseline: standard round punches only, which cannot produce oblong or special slots.
